Yüksek Performanslı PSA Azot Jeneratörü 5 - 6000 Nm3 / H Azot Kapasitesi

Temel bilgi
Menşe yeri: Çin
Marka adı: Ally Hi-Tech
Fiyat: Negotiable
Ambalaj bilgileri: Denize paketi
Detay Bilgi
Verim: Yüksek performans Otomasyon: Tam otomatik
teknoloji: modülarizasyon Güvenilirlik: Yüksek
Vurgulamak:

azot üretim sistemi

,

endüstriyel azot jeneratörü


Ürün Açıklaması

Yüksek Performanslı PSA Azot Jeneratörü 5 - 6000 Nm3 / h Azot Kapasitesi



Süreç açıklaması

A booster is used to elevate the pressure of air. Hava basıncını yükseltmek için bir yükseltici kullanılır. Then, a refrigerating dryer is introduced to remove the moisture. Daha sonra, nemi uzaklaştırmak için bir soğutucu kurutucu verilir. Finally, carbon molecular sieves beds is employed to separate the nitrogen from the oxygen, where a desirable nitrogen product will be guaranteed. Son olarak, azotu oksijenden ayırmak için karbon moleküler elek yatakları kullanılır, burada arzu edilen bir azot ürünü garanti edilir.

The adsorbent is carbon molecular sieves. Adsorban karbon moleküler eleklerdir. It is just making use of the property that the adsorption rate of oxygen and nitrogen differs on the surface of the carbon adsorbent to adsorb O2 and desorb N2. Oksijen ve azotun adsorpsiyon oranının, O2'yi adsorbe etmek ve N2'yi desorbe etmek için karbon adsorban yüzeyinde farklılık göstermesi özelliğini kullanır. The on/off valves are controlled by the programmable logic controller (PLC) to complete each cycle of adsorption and desorption and then nitrogen is produced with the required purity. Açma / kapama vanaları, her bir adsorpsiyon ve desorpsiyon döngüsünü tamamlamak için programlanabilir lojik kontrolör (PLC) tarafından kontrol edilir ve daha sonra gerekli saflıkta azot üretilir. The two adsorbers are in adsorbing and desorbing alternatively to ensure nitrogen to be generated constantly and steadily. İki adsorban, azotun sürekli ve istikrarlı bir şekilde üretilmesini sağlamak için alternatif olarak adsorbe eder ve desorbe eder.



Teknik özellikler

  • Daha az yatırımla gelişmiş teknoloji
  • Güvenilir ve azot saflığı ve miktarı sabittir
  • Modülarizasyon.
  • Tam otomatik kontrol



Verim

  • Azot Kapasitesi: 5 ~ 6.000 Nm3/ h
  • Azot Saflığı:% 95 ~% 99.999 (h / h)
  • Basınç: 0.1 ~ 1.0MPa (G)
  • Atmosferdeki Çiğ Noktası
  • Basınç: -40 ℃ ~ -55 ℃



Referans



Yüksek Performanslı PSA Azot Jeneratörü 5 - 6000 Nm3 / H Azot Kapasitesi 0
